Mini Vci J2534 Cable
I bought a cheap Chinese Mini VCI J2534 cable for diagnostics and auto settings. I used it and found that you can do a lot with it through the Toyota Techstream service program. And here he came to me: Package includes the drivers for the cable and the program itself-Toyota Techstream with V10.10.018 version.
Mini VCI is a high performance diagnostics and reprogramming interface, compatible wit SAEJ2534 (Pass-Thru), provide high speed communication to most of vehicles. Connect to PC with high speed USB 2.0. MINI VCI j2534 For Toyota TIS Techstream V10.30.029 Single Cable. MINI VCI FOR TOYOTA TIS Techstream V10.30.029 Single Cable Support Toyota TIS OEM Diagnostic Software. MINI VCI J2534 Cable for toyota TIS Techstream. Latest Version: V9.30.002. If you need Toyota obd1 to obd2 cable, pls choose Toyota 22 pin connector, so it can only do Toyota 16pin cars.
Cable for diagnosis Mini-VCI J2534 I post links for download:, drivers Then I will tell you how to install the driver and the program under Windows 7 or 8.1 x64. The instruction can be found on the Internet, but I will write it here. INSTALLATION INSTRUCTIONS Techstream on Windows 7, 8.1 – x64 bit If you bought the and there is no unpacked driver on the disk, and there is only the MVCI Driver for TOYOTA.msi installer that does not really work when installed on any Windows x64 and gives an error, and it must be installed, otherwise the sw will not work, and it does not matter. This problem can be solved by installing the MVCI Driver for TOYOTA.msi manually as follows: 1. Create a folder on drive C: Temp 2. Copy to our C: Temp folder our MVCI Driver for TOYOTA.msi file 3. With Administrator rights open and run the following command: msiexec / a “C: temp MVCI Driver for TOYOTA.msi” / qb TARGETDIR = c: temp mvci this command will extract all content from the MSI file to the C: Temp mvci folder 4.
We delete the file MVCI Driver for TOYOTA.msi from the folder C: Temp mvci, it is no longer needed, we can also remove it from the folder C: Temp 5. We go in C: Program Files (x86) and create there folder XHorse Electronics and in it one more MVCI Driver for TOYOTA TIS and move there all the contents from the folder C: Temp mvci 6.
Connect the MINI VCI cable to the USB port. IMPORTANT: When the automatic driver installation process starts, it must be canceled and the device will not be detected.
Open the Device Manager and locate the two faulty devices in the list. They will have a yellow icon indicating that Windows could not install the drivers for them. Now right click on the faulty device, select “Update Driver”, then “search on this computer” next “Browse my computer” and specify the path to “C: Program Files (x86) XHorse Electronics MVCI Driver for TOYOTA TIS “(” include subfolders “check box). Click the “Next” button and wait for the drivers to be installed. Now you should see two new devices: “Controllers USB USB Serial Converter” and “Ports (COM & LPT) USB Serial Port (COM —)”. Where instead of a line will be your figure COM port. Next, go to the path “C: Program Files (x86) XHorse Electronics MVCI Driver for TOYOTA TIS” and run the file “FirmwareUpdateTool.exe”. In the opened program, click the “Device Info” button. You should see the “connected device” graph filled.
If you see this, then your works under a 64-bit version of Windows and can be used by other programs, such as Techstream. There is a connection with the cable!
Now install Techstream using the software “Techstream.exe” of any version. after installation do not run it yet. To activate it, you need to change the TISFunction = 1 line in the C: Program Files Toyota Diagnostics Techstream Env IT3System.ini file and change it to “0” and save the file.
New hindi dubbed movies 2018 youtube. Now you need to make the program see the cable So that Techstream sees MINI-VCI under Windows x64, the Registry should be changed like this: 1.
Mini Vci J2534 Windows 10
Only copied Toyota Techstream software (latest Ver. 12.30.017) works with J2534 pass-thru. I don't think original Techstream can work on clone cable. But the clone cable and Techstream crack does work. Not bad, I can change things on my 4runner very easily. As a note, which is not specified anywhere else that I have seen, you can perform a Zero Point Calibration using this tool, I had some issues with VSC lights coming on, and was able to do the ZPC with this and cleared them out.
I would recommend this tool to anyone who owns a Toyota vehicle. I am not sure what models it works for buy I know Tacoma and 4runner are supported.
